Model

6ED1055-4MH00-0BA1

Availability:In Stock

Product Details

SIEMENS LOGO! Controller 6ED1055-4MH00-0BA1 LOGO! TD TEXTDISPLAY, 6 LINES, 3 BACKGROUND COLORS 2 ETHERNET PORTS ACCESSORIES, FOR LOGO! 8LOGO! TD TEXTDISPLAY, 6-ZEILIG, 3 HINTERGRUND-FARBEN 2 ETHERNET PORTS EINBAUZUBEHOER, FUER LOGO! 8LOGO! TD AFFI

Technical Specifications

Artikelnummer

6ED1055-4MH00-0BA1

		LOGO! TD TEXTDISPLAY, 6 LINES, 3 BACKGROUND COLORS 2 ETHERNET PORTS ACCESSORIES, FOR LOGO! 8
General information
Application area		Can be used with LOGO! 8 and higher
Delivery quantity in pieces		1
Operator control and monitoring
Illuminant		LED
Display
Design of display		FSTN
graphics-enabled		No
Line display
● Number of lines		6
● Number of characters per line		24
Control elements
Keyboard
● Keys with LED		No
● System keys		Yes
— Number of configurable system keys		0
● Numeric/alphabetical input
— Numeric keyboard		No
— Alphanumeric keyboard		No
Installation type/mounting
Wall mounting/direct mounting possible		No
Supply voltage
Type of supply voltage		AC/DC
Rated value (DC)		12 V; 12 V DC, 12/24 V AC/DC
permissible range, lower limit (DC)		10.2 V
permissible range, upper limit (DC)		28.8 V
Power losses
Power loss, typ.		1.8 W; Typical
Digital inputs
Number of digital inputs		0
Interfaces
Number of RS 232 interfaces		0
Number of other interfaces		0
Industrial Ethernet
● Number of industrial Ethernet interfaces		2
Interrupts/diagnostics/status information
Diagnostic messages
● Diagnostic functions		No
Diagnostics indication LED
● Status indicator digital input (green)		No
Standards, approvals, certificates
CE mark		Yes
KC approval		Yes
UL approval		Yes
FM approval		Yes
Marine approval
● American Bureau of Shipping (ABS)		Yes
Ambient conditions
Operating temperature
● Min.		0 °C
● max.		55 °C
Accessories
belongs to product		LOGO!
Mechanics/material
Design of housing		plastic
Type of housing (front)		plastic
● plastic		Yes
Dimensions
Width		128.2 mm
Height		86 mm
Depth		38.7 mm
Weights
Weight, approx.		220 g
Scope of supply
Delivery unit in items		1
last modified:		13.10.2014
