SIMATIC S7, PC ADAPTER USB F. CONNECTION OF S7-200/300/ 400, C7; WITH USB-CABLE (5M) CAN BE USED UNDER WINXP/VISTA/ WINDOWS 7 32/64BIT |
| Supply voltage |
| 24 V DC |
Yes |
| Input current |
| Current consumption, typ. |
100 mA |
| Power |
| Power consumption, typ. |
max. 2.5 W |
| EMC |
| Interference immunity against discharge of static electricity |
| ● Interference immunity against discharge of static electricity acc. to IEC 61000-4-2 |
Yes; 6 kV contact discharge to IEC 61000-4-2; 8 kV air discharge to IEC 61000-4-2 |
| Interference immunity to cable-borne interference |
| ● Interference immunity on supply lines acc. to IEC 61000-4-4 |
Yes; 2 kV to IEC 61000-4-4, burst |
| ● Interference immunity on signal lines acc. to IEC 61000-4-4 |
Yes; 1 kV to IEC 61000-4-4, burst, length < 3 m; 2 kV to IEC 61000-4-4, burst, length > 3 m |
| Surge immunity |
| ● on the supply lines acc. to IEC 61000-4-5 |
Yes; 1 kV (to IEC 61000-4-5; surge symm.); 2 kV (to IEC 61000-4-5; surge asymm.) |
| Immunity against high-frequency electromagnetic fields |
| ● Interference immunity against high-frequency radiation acc. to IEC 61000-4-3 |
Yes; 10 V/m, 80 to 1000 MHz (to IEC 61000-4-3); 10 V/m, 900 MHz, 1.89 GHz, 50% ED (to IEC 61000-4-3) |
| Immunity against conducted interference induced by high-frequency fields |
| ● Interference immunity against high frequency current feed acc. to IEC 61000-4-6 |
Yes; 10 V, 9 kHz to 80 MHz (to IEC 61000-4-6) |
| Immunity to magnetic field interference |
| ● Interference immunity to magnetic fields at 50 Hz |
30 A/m; to IEC 61000-4-8 |
| Emission of radio interference acc. to EN 55 022 |
| ● Interference emission acc. to EN 55022, class B |
Yes |
| Ambient conditions |
| Operating temperature |
| ● Min. |
5 °C |
| ● max. |
40 °C |
| ● Permissible temperature change |
10 °C/h; Operation: 10 K/h; storage/transport: 20 K/h |
| Storage/transport temperature |
| ● Min. |
-20 °C |
| ● max. |
60 °C |
| Relative humidity |
| ● Operation, min. |
5 % |
| ● Operation, max. |
80 %; At 25 °C (no condensation) |
| ● Storage/transport, min. |
5 % |
| ● Storage/transport, max. |
95 %; At 25 °C (no condensation) |
| Vibrations |
| ● Operation, checked according to IEC 60068-2-6 |
Yes; 10 to 58 Hz: Amplitude 0.075 mm; 58 to 500 Hz: Acceleration 9.8 m/s2 |
| ● Transport tested checked to IEC 60068-2-6 |
Yes; (packed) 5 to 9 Hz, amplitude 3.5 mm; 9 to 500 Hz, acceleration 9.8 m/s2 |
| Shock test |
| ● Shock test |
Tested to DIN IEC 60068-2-2; Operation: 950 m/s2 (10 g), 30 ms, 100 Shocks; Transport (packaged): 250 m/s2 (25 g), 6 ms, 1000 shocks |
| Dimensions |
| Width |
105 mm |
| Height |
58 mm |
| Depth |
26 mm |
| Weights |
| Weight, approx. |
100 g |
| last modified: |
13.10.2014 |
