Model

6ES7272-1AA10-0YA1

Availability:In Stock

Product Details

SIEMENS S7-200 6ES72721AA100YA1 SIMATIC S7-200, TD200C,CUSTOMIZ. TXT DISPL. F. S7-200,,2 LINES, WITH CABLE (2.5M) AND,MOUNTING ACCESSORIES,,CONFIGURATION WITH,STEP7-MICRO/WIN,WITHOUT ATEX CERTIFICATESIMATIC S7-200, TD200C,ANPASSB. TEXTDISPLAY F. S7-200,,2

Technical Specifications

Artikelnummer

6ES7272-1AA10-0YA1

		SIMATIC S7-200, TD200C CUSTOMIZ. TXT DISPL. F. S7-200, 2 LINES, WITH CABLE (2.5M) AND MOUNTING ACCESSORIES, CONFIGURATION WITH STEP7-MICRO/WIN WITHOUT ATEX CERTIFICATE
Operator control and monitoring
Operating/fault messages
● Number of lines		2
● Number of characters per line		20; Characters/line: ASCII, cyrillic; 10 characters/line: Chinese
● Character size		5 mm
Display
Design of display		LCD backlit
Supply voltage
Rated value (DC)		24 V; Power supply via the S7-200 communications interface or optional external power supply unit; the CPU sensor power supply (24 V DC) is not subjected to load
Input current
Rated value at 24 V DC		120 mA
Interfaces
Point-to-point
● Transmission rate, max.		187.5 kbit/s
1. Interface
Physics		RS 485
Functionality
● PPI		Yes
PPI
● Number of nodes, max.		126; S7-200, OP, TP, TBP, PG / PC
Degree and class of protection
IP65		Yes; at front
Ambient conditions
Operating temperature
● min.		0 °C
● max.		60 °C
Storage/transport temperature
● min.		-20 °C
● max.		70 °C
Dimensions
Width		148 mm
Height		76 mm
Depth		28 mm
Mounting cutout/device depth (W x H x D)
● Mounting cutout, width		138 mm
● Mounting cutout, height		68 mm
Cabinet/switchboard thickness		0.3 mm; 0.3 to 4 mm
Weights
Weight, approx.		200 g
last modified:		21.08.2014
