Model

IM 153

PROFIBUS-DP

Product  Description

·Profibus-DP interface module to connect remote I/O modules with Profibus protocol

·Eight  300 expasion modules can be used each IM 153-1

Modules characteristic

Protocol

PROFIBUS-DP

Baud rate,Max

12Mbps Automatic adapt

Address space, Max

128bits input/128bits output

Expansion modules,Max

8

Isolation voltage

500V

Work voltage

24V DC

Current consumption

(24V DC)

625mA

Degree of protection

IP20

Operating temprature

-10℃~ 70℃

Dimensions

(W x H x D)(mm)

40×125×120

Order Number

 153-1AA03-0XB0
